P3015 Full Cover CNC Laser Cutter

High-power, fully enclosed fiber laser cutting system designed for maximum safety, precision, and eco-friendly operation.

Product Gallery

Safety & Eco-Friendly for High-Power Fiber Laser Cutters

Full Enclosure Safety

The fully enclosed design creates a safe cutting zone, eliminating direct exposure to laser radiation.

CE-Approved Protection

The observation window is fitted with CE-compliant laser protective glass for reliable safety.

Zero Pollution Operation

Integrated internal filtration captures cutting smoke, delivering clean, eco-friendly performance.

Technical Specifications

Parameter	Specification
Model	P Series Fiber Laser Cutting Machine
Laser Power	1500W, 3000W, 6000W, 8000W, 10000W, 12000W, 15000W, 20000W
Laser Wave Length	1064 nm
Working Table	Sawtooth
Maximum Idle Running Speed	120 m/min
Maximum Acceleration	1.5G
Position Accuracy	±0.02 mm/m
Repeat Positional Accuracy	±0.01 mm
Position Type	Red Dot
Power Consumption	≤21 kW
Working Voltage	380V / 50Hz
Auxiliary Gas	Oxygen, Nitrogen, Air
Working Life of Fiber Module	More than 100,000 hours
Cooling Type	Water-cooling
Work Environment	0-45°C, Moisture 45-85%
